Given that we are now in February 2026, the logistics landscape has shifted toward high-efficiency, tech-integrated assets. Below is the updated technical spec sheet and localized delivery roadmap for the 40ft High Cube Reefer Container—the definitive king of the 2026 cold chain.
Technical Specification Sheet: 2026 High Cube Reefer
| Feature | Imperial Measurement | Metric Measurement |
| External Length | 40’ 0” | 12.192 m |
| External Width | 8’ 0” | 2.438 m |
| External Height | 9’ 6” | 2.896 m |
| Internal Length | 38’ 0” | 11.588 m |
| Internal Width | 7’ 6” | 2.290 m |
| Internal Height | 8’ 4.3” | 2.547 m |
| Max Gross Weight | 77,162 lbs | 35,000 kg |
| Average Tare Weight | 10,050 lbs | 4,560 kg |
| Max Payload | 67,112 lbs | 30,440 kg |
| Internal Capacity | 2,387 cu. ft. | 67.6 m³ |
Standard 2026 Industrial Load-Out:
- Machinery: Choice of Carrier PrimeLINE (Best for energy efficiency) or Thermo King Magnum Plus (Best for rapid pull-down speeds).
- Flooring: 30mm Extruded Aluminum T-Bar (Designed for 2026-standard pallet jack weights).
- Insulation: High-density polyurethane foam (Zero-CFC) providing a thermal range from -30°C to +30°C.
- Lining: Food-grade HGSS (High-Grade Stainless Steel) or MGSS side panels for maximum bacteria resistance and easy wash-down.
Delivery Timeline Roadmap (Q1 2026)
While global shipping routes remain impacted by 2025’s capacity shifts, Steel Works Shipping Containers utilizes local inventory hubs to bypass port congestion. Here is what you can expect for your delivery:
Stage 1: Order Processing & PTI (1–2 Days)
Every reefer undergoes a Pre-Trip Inspection (PTI). Our technicians run the unit for a full 12-hour cycle to ensure the 2026-spec digital controllers and sensors are calibrated perfectly for your specific cargo.
Stage 2: Transit Time by Region
- Major Port Hubs (LA, Houston, Savannah, Newark): 2–4 Business Days. These cities benefit from our proximity to primary storage yards.
- Inland Industrial Centers (Chicago, Dallas, Atlanta): 4–7 Business Days. We utilize dedicated tilt-bed trailers for “ground-drop” delivery.
- Canadian Corridors (Vancouver, Montreal, Quebec City): 7–10 Business Days. Includes time for standard customs clearance and cross-border logistics.
Stage 3: Site Placement (1–3 Hours)
Once the truck arrives at your zip code, our driver will work with you to place the unit. Because it is a 40ft High Cube, we require approximately 100 feet of straight-line clearance to slide the unit off the trailer.
Next Step for Your Zip Code
To give you a “To-the-Minute” delivery window and a final landed price, I need to check the real-time carrier availability in your specific area.
